Temperature Controllers
|
|
 |
Temperature Controllers
Manufactured by Autonics Korea
|
|
|
|
TX4S Digital Temperature Controller
- Large backlit LCD display with wide viewing angle
- Display measured temperature & set point
- Panel mount DIN 48x48mm
- On/Off or PID control
- SPST relay 250Vac 3A
- Alarm relay output
- Pt100, type K & type J input
- Accuracy ±0.3% of full scale
- Supply 100 to 240Vac 8VA max.
|
|
|
|
TAS Temperature Controller
- Analogue dial setting type
- 48x48mm 8 pin plug-in
- On/Off or PID control
- SPDT relay 250Vac 2A
- Panel mount 48x48mm
- Type K inputs, 100°C, 200°C, 400°C, 800°C
- Type J input 200°C
- Pt100 inputs, 100°C, 200°C
- Accuracy ±2% of full scale
- Supply 90 to 264Vac 2.2VA
|
|
|
|
T3S Digital Temperature Controller
- 3 x 7 segment LED display
- On/Off or proportional control
- Single pole relay 250Vac 2A
- Panel mount 48x48mm
- Type K inputs, 399°C, 799°C, 999°C
- Type J inputs, 199°C, 399°C, 499°C, 799°C
- Pt100 inputs, 99.9°C, 199°C, 399°C
- Accuracy ±1% of full scale
- Supply 90 to 264Vac 5VA
|
|
|
|
|
TC3YF Digital Temperature Controller
Cooling/defrost temperature controller with NTC sensor
- On/off control
- Large high luminance LED display
- Panel mount 72x36mm
- Compressor, defrost & evaporation outputs
- Relay output
- Wide range power supply, 100 to 240Vac, <5VA
|
|
|
|
TC4Y Digital Temperature Controller
- PID control algorithm
- Large high luminance LED display
- Panel mount 72x36mm
- Pt100, type J or K thermocouple sensor
- Accuracy ±0.5%
- Relay & SSR output
- Wide range power supply, 100 to 240Vac, <5VA
|
|
|
|
TC4L Digital Temperature Controller
- PID control algorithm, 100ms high speed sampling
- Large high luminance LED display
- Panel mount 96x96mm
- Pt100, type J or K thermocouple sensor
- Accuracy ±0.5%
- Relay & SSR output
- Alarm output
- Wide range power supply, 100 to 240Vac, <5VA
|
|
|
Temperature Indicator
Manufactured by Autonics Korea
|
|
| |
Model T4YI
|
|
Model T4YI Digital Temperature Indicator
Panel mount - 72 x 36mm
4 digit LED display
Pt100 sensor
-99.9°C to 199.9°C
Supply 100 to 240V ac 3VA 50/60Hz
|
 |
Temperature Controllers
Manufactured by Panasonic
|
|
|
|
KT7, KT4 Digital Temperature Controllers
- Thermocouple, RTD, dc current or voltage input
- PID, on/off control modes
- Accuracy ±0.2% span
- Relay or O/C output
- 24V ac/dc & 100-240Vac supply options
- KT7 DIN rail 22.5mm x 75mm, KT4 48mm x 48mm
- Optional outputs for alarms, comms etc.
|
|
 |
Temperature Relay
Manufactured by Comadan Produktion A/S Denmark
|
|
|
|
RM34 Pt100 Temperature Relay
- AC supplies 24V, 115V and 230V ±10% 40-70Hz 3VA
- DC supply 12 to 50V
- 4 ranges from -50°C to +200°C
- Built in cable resistance compensation
- Adjustable set point and reaction delay
- Relay release on cable short/break
- Pt100 input, selectable ranges:
-50 to +50°C, 0 to 100°C, 50 to 150°C, 100 to 200°C
- 1 pole 8A 250Vac relay output
- Standard 11 pin relay connection
|
ZB11 base |
|
|
|
Data sheet
